3.5 kVA - 5 kVA
3.5 kVA - 5 kVA
Kirloskar Diesel Generators
Power on Wheels: KCC rolls on wheels and is equipped with a wide length handle. Mobile power backup can be convenient both for business or pleasure. From construction sites to wedding celebrations. This feature is of great help for small establishments and mobile workshops too.
- Ergonomically designed handle
- Specially designed wheels
- Easy manoeuvrability
Features
| Rated/Max Power Output (VA) : | 3000 VA |
| Installation & Commissioning : | Labour Free on-site |
| Compliance : | Latest Government Emission Norms CPCB II |
| Start Type : | Controller Based Easy Push Start |
| Service : | Labour free onsite service under warranty period (420+ service touch points and 6000+ Kirloskar trained service professionals on field) |
Product Specifications
India's #1 Genset brand
| Specifications | 3kVA | 3kVA SSG | 5kVA | 5kVA SSG |
| SKU | ELE.POR.19420220 | EL.PO.PO.1610702 | EL.PO.PO.1610703 | EL.PO.PO.1610704 |
| Rated/Max Power Output (VA) | 3000 VA | 3000 VA | 5000/5500 VA | 5000/5500 VA |
| Installation & Commissioning | Labour Free on-site | |||
| Compliance | Latest Government Emission Norms CPCB II | |||
| Start Type | Controller Based Easy Push Start | |||
| Service | Labour free onsite service under warranty period (420+ service touch points and 6000+ Kirloskar trained service professionals on field) | |||
| Type of Product | Portable Genset | |||
| Comparison Method | 55% savings over petrol gensets | |||
| Fuel Consumption (At 50% Load) | 0.6 ltrs/hr | 0.6 ltrs/hr | 0.9 ltrs/hr | 0.9 ltrs/hr |
| Fuel Consumption (At 75% Load) | 0.75 ltrs/hr | 0.75 ltrs/hr | 1.2 ltrs/hr | 1.2 ltrs/hr |
| Fuel Consumption (At 100% Load) | 1 ltrs/hr | 1 ltrs/hr | 1.5 ltrs/hr | 1.5 ltrs/hr |
| Lube. Oil Capacity (ml) | 1100 ml | 1100 ml | 1650 ml | 1650 ml |
| Fuel Type | Diesel | |||
| Dry Weight (Kg) | 180 kg | 190 Kg | 190 Kg | |
| Features | Number of Cylinder: 1 | |||
| Dimensions (mm) | 1150X560X840 | 920X560X920 mm | 1150X560X840 mm | 970X580X970 mm |
| Frequency | 50 Hz | |||
| Rated Voltage | 230 V | |||
| Model No | CC1-3AS2 | CC1-3AS | CC1-5AS | CC1-5AS2 |
| Sound Level | <70 dba | <75 dba | <75 dba | <75 dba |
| Fuel Tank Capacity | 13 L | 13 L | 12.5 L | 13 L |
| Engine Model No | CC306 G1 | CC306 G1 | CC418 G1 | CC418 G1 |
